Lexus LC I (2016-2024) left fuel pump w/ seal sub-assembly Wiring diagram
This page shows the only wiring diagram for the component.left fuel pump w/ seal sub-assembly, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left fuel pump w/ seal sub-assembly (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DIRECT FUEL INJECTOR ASSEMBLY 1
DIRECT FUEL INJECTOR ASSEMBLY 4
DIRECT FUEL INJECTOR ASSEMBLY 6
DIRECT FUEL INJECTOR ASSEMBLY 7
FP-
FPD +
GRN WIRE
GRY WIRE
INJF
LEFT CAM TIMING CONTROL W/ EDU MOTOR ASSEMBLY
LEFT FUEL PUMP W/ SEAL SUB-ASSEMBLY
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL/BLK WIRE
REAR OF ENGINE COMPT)
RED WIRE
RIGHT CAM TIMING CONTROL W/ EDU MOTOR ASSEMBLY
SGND
SHIELD
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l (8 of 12) -> LEFT FUEL PUMP W/ SEAL SUB-ASSEMBLY
