Lexus LC I (2016-2024) left front height control sensor sub-assembly Wiring diagram
This page shows the only wiring diagram for the component.left front height control sensor sub-assembly, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front height control sensor sub-assembly (1 of 1)
ABSORBER CONTROL ECU
AIR CONDITIONING AMPLIFIER ASSEMBLY
AVS FUSE
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DRIVER SIDE J/B
ECO
ECOS
EXCEPT HYBRID
FAL+
FAR-
GRN WIRE
GRY WIRE
HOT W/
HYBRID VEHICLE CONTROL ECU ASSEMBLY
IGB
LEFT ACCELERATION SENSOR
LEFT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY
LEFT FRONT SHOCK ABSORBER ASSEMBLY
LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
LEFT REAR SHOCK ABSORBER ASSEMBLY
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM R/B 2
NORM
NORMAL
PC (LEFT KICK PANEL)
PNK WIRE
PPL GND
PPL/BLK WIRE
PPL/PNK WIRE
PWMS
RAL+
RAR+
RED WIRE
RELAY ENERGIZED
RIGHT ACCELERATION SENSOR
RIGHT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY
RIGHT FRONT SHOCK ABSORBER ASSEMBLY
RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
RIGHT REAR SHOCK ABSORBER ASSEMBLY
RIGHT REAR SKID CONTROL SENSOR WIRE
SGB
SGFL
SGFR
SGG
SHB
SHFL
SHFR
SHG
SHRL
SHRR
SPCN
SPORT
SPRT
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic suspension circuit -> LEFT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY
