Lexus LC I (2016-2024) driver exhaust change valve 2 Wiring diagram
This page shows the only wiring diagram for the component.driver exhaust change valve 2, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver exhaust change valve 2 (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER EXHAUST CHANGE VALVE 1
DRIVER EXHAUST CHANGE VALVE 2
EXHAUST PIPE GAS CONTROL ACTUATOR SUB-ASSEMBLY 1
EXHAUST PIPE GAS CONTROL ACTUATOR SUB-ASSEMBLY 2
EXVI
EXVO
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OXYGEN SENSOR (BANK 1 SENSOR 2)
OXYGEN SENSOR (BANK 2 SENSOR 2)
PNK WIRE
PPL
PPL/BLU WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
RED WIRE
SHIELD
VCS
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l (5 of 12) -> DRIVER EXHAUST CHANGE VALVE 2
