Lexus LC I (2016-2024) blk Wiring diagrams
This page contains all the electrical diagrams for the component. blk, in which he is found in the car Lexus LC I (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
blk wiring diagram (131 of 169)
BATT FAN 1 FUSE
BATT FAN 1 RELAY
BATTERY COOLING BLOWER ASSEMBLY
BATTERY ECU ASSEMBLY
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGCT 1 RELAY ENERGIZED
HV SUPPLY BATTERY ASSEMBLY
IGCT
IGCT 5 FUSE
LT GRN WIRE
LUGGAGE ROOM R/B 2
PNK WIRE
PPL/RED WIRE
RED WIRE
VIO WIRE
WHT/BLK WIRE
XE (UNDER REAR SEATS)
Go to component -> Battery cooling fan circuit -> BLK WIRE
blk wiring diagram (133 of 169)
ACL
AIR BAG ECU ASSEMBLY
BLK WIRE
BLU WIRE
DRIVER SIDE J/B
DRIVING SUPPORT ECU ASSEMBLY
FORWARD RECOGNITION CAMERA
GRN WIRE
GRY WIRE
LEFT BLIND SPOT MONITOR SENSOR
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
ORG/ WIRE
PEDESTRIAN DETECTION ECU ASSEMBLY
PNK WIRE
RED WIRE
STEERING SENSOR
VIO WIRE
W/O VGRS
WHT WIRE
YAW RATE SENSOR
YEL WIRE
Go to component -> Computer data lines circuit (6 of 8) -> BLK WIRE
blk wiring diagram (135 of 169)
BATTERY ECU ASSEMBLY
BATTERY STATE SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CAN (+)
CANL PPL CANH
COMPRESSOR W/ MOTOR ASSEMBLY
DOUT
GRN WIRE
GRY WIRE
HV SUPPLY BATTERY ASSEMBLY
HYBRID VEHICLE CONTROL ECU ASSEMBLY
IN LUGGAGE COMPT)
INVERTER W/ CONVERTER ASSEMBLY
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL/VIO WIRE
RED WIRE
SHIFT CONTROL ECU
SUB-BATTERY W/ CONTROL ASSEMBLY
VEHICLE APPROACHING SPEAKER CONTROLLER
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (8 of 8) -> BLK WIRE
blk wiring diagram (136 of 169)
AM (LEFT SIDE OF DASH)
BLK WIRE
BLK/DK GRN WIRE
BRAKE BOOSTER PUMP W/ ACCUMULATOR ASSEMBLY
BRN WIRE
CAN JUNCTION TERMINAL 2
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
DK GRN WIRE
FAN W/ MOTOR ASSEMBLY
HEATER ACCESSORY ASSEMBLY
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT FRONT POWER SEAT SWITCH
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
LEFT REAR SEAT INNER BELT ASSEMBLY 1
LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
LEFT SEAT HEATER (LEFT FRONT SEAT CUSHION HEATER ASSEMBLY)
PPL
REAR OF ENGINE COMPT)
RIGHT FRONT MARKER LIGHT ASSEMBLY
RIGHT FRONT TURN SIGNAL LIGHT ASSEMBLY
RIGHT HEADLIGHT CONTROL ECU ASSEMBLY (RIGHT HEADLIGHT ASSEMBLY)
SKID CONTROL ECU ASSEMBLY
STOP LIGHT SWITCH ASSEMBLY
SUB-BATTERY W/ CONTROL ASSEMBLY
WHT WIRE
WHT/BLK WIRE
XA (UNDER DRIVER'S SEAT)
Go to component -> Ground distribution circuit (2 of 7) -> BLK WIRE
blk wiring diagram (137 of 169)
A/F HTR RELAY
AE (LEFT FRONT OF ENGINE COMPT)
AJ (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
CAN JUNCTION TERMINAL 1
CLEARANCE WARNING ECU ASSEMBLY
EFI- MAIN 1 RELAY
INV W/ PMP RELAY
INVERTER WATER PUMP ASSEMBLY (W/ MOTOR)
LEVEL WARNING SWITCH ASSEMBLY
OCCUPANT DETECTION ECU
OIL PMP RELAY
PPL
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT POSITION CONTROL ECU ASSEMBLY
RIGHT REAR SEAT INNER BELT ASSEMBLY
RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
RIGHT SEAT HEATER (RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY)
SEMICONDUCTOR POWER INTEGRATION ECU 1
THEFT WARNING SIREN ASSEMBLY
VEHICLE APPROACHING SPEAKER CONTROLLER
WHT WIRE
WHT/BLK WIRE
WIPER RELAY 1
WIPER RELAY 2
XD (RIGHT KICK PANEL)
Go to component -> Ground distribution circuit (3 of 7) -> BLK WIRE
blk wiring diagram (138 of 169)
ACC P RELAY
BATT FAN 1 RELAY
BLK WIRE
BRAKE CONTROL POWER SUPPLY W/ BRACKET ASSEMBLY
EFI MAIN 2 RELAY
FROM GROUND PF (DIAGRAM 4 OF 7)
FRONT STEERING CONTROL ECU
FUEL PUMP CONTROL ECU
GF (RIGHT FRONT OF ENGINE)
HYBRID VEHICLE CONTROL ECU ASSEMBLY
IGCT 1 RELAY
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 5
LEAK DETECTION PUMP SUB-ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LUG- ACC RELAY
LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
LUGGAGE ROOM J/B 1
LUGGAGE ROOM R/B 2
PANEL P RELAY
PARKING BRAKE ECU ASSEMBLY
PG (RIGHT KICK PANEL)
PPL
SEMICONDUCTOR POWER INTEGRATION ECU 3
SHIFT CONTROL ECU
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
SPOILER CONTROL ECU ASSEMBLY
STEERING PAD SWITCH ASSEMBLY RIGHT STEERING PAD SWITCH
SWITCH WIRE 2
TRUNK OPN RELAY
WHT WIRE
Go to component -> Ground distribution circuit (5 of 7) -> BLK WIRE
blk wiring diagram (139 of 169)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 2) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 2) SHIELD
BLK WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
DATA LINK CONNECTOR 3
ECM SHIELD
FROM GF GROUND (DIAGRAM 5 OF 7)
FRONT WIPER DEICER (WINDSHIELD GLASS)
FUEL INJECTOR ASSEMBLIES 1, 3, 5 (FOR DIRECT INJECTION) SHIELD
FUEL INJECTOR ASSEMBLIES 2, 4, 6 (FOR DIRECT INJECTION) SHIELD
FUEL PUMP ASSEMBLY SHIELD
KNOCK CONTROL SENSOR (BANK 1), KNOCK CONTROL SENSOR (BANK 2) SHIELD
QUICK HEATER ASSEMBLY
REAR OF ENGINE COMPT)
SHIELD
VIO WIRE
WHT WIRE
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY 2
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (7 of 7) -> BLK WIRE
blk wiring diagram (140 of 169)
BLK WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DRIVER SIDE J/B
GRN WIRE
GRY WIRE
LT BLU WIRE
PASSENGER SIDE J/B
PNK WIRE
PPL/BLK WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SP-
VEHICLE APPROACHING SPEAKER ASSEMBLY
VEHICLE APPROACHING SPEAKER CONTROLLER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Vehicle proximity notification circuit -> BLK WIRE
