Lexus LC I (2016-2024) battery fan relay 1 Wiring diagram
This page shows the only wiring diagram for the component.battery fan relay 1, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery fan relay 1 (1 of 1)
BATTERY FAN RELAY 1
BATTERY STATE SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
GMT
GMTG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HYBRID VEHICLE CONTROL ECU ASSEMBLY
IGCT 1 FUSE
IGCT 1 RELAY
IGCT 2 FUSE
IGCT 3 FUSE
IGCT 4 FUSE
IGCT 5 FUSE
IGCT 6 FUSE
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM R/B 2
OHG
OHU
OHV
OHW
OIGH
OIL PUMP MOTOR CONTROLLER
OIL PUMP W/ MOTOR ASSEMBLY
OPST
PM IGCT FUSE
PNK WIRE
PPL/BLK WIRE
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
SIG
TPST
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l hybrid, hybrid system circuit (1 of 11) -> BATTERY FAN RELAY 1
