Lexus LC I (2016-2024) battery cooling blower assembly Wiring diagrams
This page contains all the electrical diagrams for the component. battery cooling blower assembly, in which he is found in the car Lexus LC I (2016-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram battery cooling blower assembly (1 of 2)
BATT FAN 1 FUSE
BATT FAN 1 RELAY
BATTERY COOLING BLOWER ASSEMBLY
BATTERY ECU ASSEMBLY
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGCT 1 RELAY ENERGIZED
HV SUPPLY BATTERY ASSEMBLY
IGCT
IGCT 5 FUSE
LT GRN WIRE
LUGGAGE ROOM R/B 2
PNK WIRE
PPL/RED WIRE
RED WIRE
VIO WIRE
WHT/BLK WIRE
XE (UNDER REAR SEATS)
Go to component -> Battery cooling fan circuit -> BATTERY COOLING BLOWER ASSEMBLY
Wiring diagram battery cooling blower assembly (2 of 2)
ABSORBER CONTROL ECU
BACKUP LIGHT ASSEMBLY
BATTERY
BATTERY COOLING BLOWER ASSEMBLY
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
CENTER STOP LIGHT W/O HARNESS ASSEMBLY
COMPRESSOR W/ MOTOR ASSEMBLY
FRONT STEERING CONTROL ECU
FUEL LID LOCK W/ MOTOR ASSEMBLY
HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY)
HV SUPPLY BATTERY ASSEMBLY
HYBRID VEHICLE CONTROL ECU ASSEMBLY
INVERTER W/ CONVERTER ASSEMBLY
LEFT BLIND SPOT MONITOR SENSOR
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT FRONT MARKER LIGHT ASSEMBLY
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT FRONT TURN SIGNAL LIGHT ASSEMBLY
LEFT HEADLIGHT CONTROL ECU ASSEMBLY (LEFT HEADLIGHT ASSEMBLY)
LICENSE PLATE LIGHT SUB-ASSEMBLY
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
PPL
PPL PPL
PPL/ PPL/ PPL/
RACK, PINION POWER STEERING GEAR ASSEMBLY
REAR STEERING CONTROL ECU
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT DOOR OUTSIDE HANDLE SUB- ASSEMBLY
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR SKID CONTROL SENSOR WIRE
SMOG VENTILATION SENSOR
STEREO COMPONENT AMPLIFIER ASSEMBLY
STEREO COMPONENT EQUALIZER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
XE (UNDER REAR SEATS)
YEL WIRE
Go to component -> Ground distribution circuit (1 of 7) -> BATTERY COOLING BLOWER ASSEMBLY
