Lexus LC I (2016-2024) automatic glare- resistant ec mirror Wiring diagram
This page shows the only wiring diagram for the component.automatic glare- resistant ec mirror, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic glare- resistant ec mirror (1 of 1)
AUTOMATIC GLARE- RESISTANT EC MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SIDE J/B
EC+
ECI+
GARAGE DOOR OPENER
GRN WIRE
HOT AT ALL TIMES
HOT W/
IG PPL
INNER REAR VIEW MIRROR ASSEMBLY
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAP LIGHT SUB-ASSEMBLY
MPX-B D 1 FUSE
PPL
PPL/BLK WIRE
PPL/LT BLU WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/VIO WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit -> AUTOMATIC GLARE- RESISTANT EC MIRROR
