Shift interlock circuit for Lexus IS III facelift (2015-2020)
Shift interlock circuit
3.5L
3.5L 2.0L TURBO
BLK WIRE
BLU WIRE
CAN (+)
CERTIFICATION ECU (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
ENGINE ROOM R/B 2 ASSEMBLY
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
P POSITION DETECTION SWITCH
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
RED WIRE
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SHIFT LOCK SOLENOID
SHIFT POSITION INDICATOR
SLS+
STOP FUSE
STOP LAMP SWITCH ASSEMBLY
TRANSMISSION CONTROL ECU ASSEMBLY
WHT WIRE
WHT/BLK WIRE
