Rear window sun shade circuit for Lexus IS III facelift (2015-2020)
Rear window sun shade circuit
2.0L TURBO
3.5L
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
ECU-B FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
J/C 1
J/C 4 (3.5L) J/C 15 (2.0L TURBO)
LT BLU WIRE
MAIN BODY ECU
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH ASSEMBLY
REAR SUNSHADE RELAY (REAR WINDOW SHADE ASSEMBLY)
REAR SUNSHADE SWITCH ASSEMBLY
RED WIRE
REV
SHADE RR FUSE
WHT/BLK WIRE
YEL WIRE
