Rear sonar circuit for Lexus IS III facelift (2015-2020)

Rear sonar circuit (1 of 2)

IS Lexus III facelift (2015-2020): Rear sonar circuit (1 of 2)

Get access

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CBZ CLEARANCE WARNING ECU (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE IG+ PNK WIRE INSTRUMENT PANEL J/B ASSEMBLY LEFT FRONT CENTER ULTRASONIC SENSOR 2 LEFT FRONT ULTRASONIC SENSOR 1 LEFT REAR ULTRASONIC SENSOR 1 LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT CENTER ULTRASONIC SENSOR 2 RIGHT REAR CENTER ULTRASONIC SENSOR 1 RIGHT REAR ULTRASONIC SENSOR 1 VIO WIRE WHT WIRE

Rear sonar circuit (2 of 2)

IS Lexus III facelift (2015-2020): Rear sonar circuit (2 of 2)

Get access

2.0L TURBO 3.5L 3.5L ACC RELAY BLK WIRE BLU WIRE BRN WIRE CAN I/F CLEARANCE WARNING BUZZER 1 COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY) DISPLAY DRIVER ECM (LEFT SIDE OF ENGINE COMPT) ECU-ACC FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY KC (RIGHT KICK PANEL) LED DRIVER LEFT REAR CENTER ULTRASONIC SENSOR 1 LT GRN WIRE METER FUSE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH ASSEMBLY RED WIRE RELAY ENERGIZED RIGHT FRONT ULTRASONIC SENSOR 1 TELLTALES VIO WIRE
