Wiring diagram red (101 of 135)
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECCS
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE ROOM J/B 2 ASSEMBLY
ETHO
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
IGN 1 FUSE
INSTRUMENT PANEL J/B ASSEMBLY
NTB
NTO
ORG/ WIRE
PNK WIRE
RED WIRE
SFTD
SFTU
SLT-
SLU+
SNOW
SNSW
SNWI
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 2.0l turbo, transmission circuit (1 of 3) -> RED WIRE
Wiring diagram red (102 of 135)
ACC RELAY
BLK WIRE
BLU WIRE
BRN WIRE
DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
ECU-ACC FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
LEFT PADDLE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT PADDLE
SHIFT SWITCH
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
SWITCH WIRE 1
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
VIO WIRE
WHT WIRE
Go to component -> 2.0l turbo, transmission circuit (2 of 3) -> RED WIRE
Wiring diagram red (103 of 135)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
GRN WIRE
GRY WIRE
HOT W/
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT BLU WIRE
LT GRN WIRE
METER FUSE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
RED WIRE
SHIFT POSITION INDICATOR
SPEAKER
SPI+
STARTING/ CHARGING SYSTEM
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 2.0l turbo, transmission circuit (3 of 3) -> RED WIRE
Wiring diagram red (105 of 135)
+BM
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 2 ASSEMBLY
ETCS FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
NT-
NTB
NTO
ORG/ WIRE
PNK WIRE
PWMS
RED WIRE
SFTD
SFTU
SHIFT POSITION INDICATOR
SNWI
SPCN
TRANSMISSION REVOLUTION SENSOR (COUNTER GEAR)
TRANSMISSION REVOLUTION SENSOR (TURBINE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 3.5l, a/t circuit (1 of 4) -> RED WIRE
Wiring diagram red (106 of 135)
ACC RELAY
BLK WIRE
BLU WIRE
BRN WIRE
DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
ECU-ACC FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
LEFT PADDLE SHIFT SWITCH
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY (RIGHT SIDE OF TRANSMISSION)
PNK WIRE
RED WIRE
RIGHT PADDLE SHIFT SWITCH
SDN
SFTD
SFTU
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
STARTING/ CHARGING SYSTEM
SUP
SWITCH WIRE 1
THROTTLE BODY W/ MOTOR ASSEMBLY (TOP RIGHT REAR OF ENGINE)
TRANSMISSION CONTROL SWITCH (TRANSMISSION FLOOR SHIFT ASSEMBLY)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> 3.5l, a/t circuit (2 of 4) -> RED WIRE
Wiring diagram red (107 of 135)
A/C AMPLIFIER ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVER DISPLAY
ECO
ECOS
GRN WIRE
GRY WIRE
IGN 2 FUSE
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL J/B ASSEMBLY
LED DRIVER
LT BLU WIRE
LT GRN WIRE
METER FUSE
NORMAL
ORG/ WIRE
PNK WIRE
PUSH
RED WIRE
RELAY ENERGIZED
SNOW
SPEAKER
SPORT
SPORT S/S+
STOP LIGHT SWITCH ASSEMBLY (TOP OF BRAKE PEDAL ASSEMBLY)
TELLTALES
VIO WIRE
W/O ADAPTIVE VARIABLE SUSPENSION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> 3.5l, a/t circuit (3 of 4) -> RED WIRE
Wiring diagram red (109 of 135)
2.0L TURBO
3.5L
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT END OF DASH)
COMPUTER DATA LINES SYSTEM
DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY)
ENGINE ROOM R/B 2 ASSEMBLY
GRY WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT PANEL J/B ASSEMBLY
LT BLU WIRE
LT GRN WIRE
P POSITION DETECTION SWITCH
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
RED WIRE
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SHIFT LOCK SOLENOID
SHIFT POSITION INDICATOR
SLS+
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
TRANSMISSIONS SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> RED WIRE
Wiring diagram red (110 of 135)
BLK WIRE
BRN WIRE
CERTIFICATION ECU
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
GRN WIRE
HOT AT ALL TIMES
ID CODE BOX
IGE
IGN 2 FUSE
INSTRUMENT PANEL J/B ASSEMBLY
LIN
LIN 1
ORG/ WIRE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SL/R
SLP
STEERING COLUMN)
STEERING LOCK ACTUATOR ASSEMBLY
STRG LOCK FUSE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Steering column circuit -> RED WIRE
