Lexus IS III facelift 2 (2020-2024) left rear height control sensor sub-assembly Wiring diagram
This page shows the only wiring diagram for the component.left rear height control sensor sub-assembly, which is found in the car Lexus IS III facelift 2 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear height control sensor sub-assembly (1 of 1)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN
DAYTIME RUNNING/ CLEARANCE
ECUB
ENGINE ROOM R/B 1 ASSEMBLY
FRONT SIDE MAKER CLEARANCE
FRWA
GRN WIRE
GRY WIRE
H-LP LH RELAY
H-LP MAIN LH FUSE
H-LP MAIN RH FUSE
H-LP RH RELAY
HEADLIGHT LEVELING ACTUATOR
HIGH/LOW
HLC
HOT AT ALL TIMES
LEFT HEADLIGHT ASSEMBLY (HEADLIGHT ECU SUB-ASSEMBLY)
LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
LINL
LT GRN WIRE
NCA WIRE
ORG/ WIRE
RED WIRE
RIGHT HEADLIGHT ASSEMBLY (HEADLIGHT ECU SUB-ASSEMBLY)
SBR
SGR
SHB
SHRL
TNS
VIO WIRE
W/ HEADLIGHT BEAM LEVEL CONTROL
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SYSTEM
Go to component: -> Headlights circuit (2 of 2) -> LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY
