Lexus IS III facelift 2 (2020-2024) cruise control main switch Wiring diagram
This page shows the only wiring diagram for the component.cruise control main switch, which is found in the car Lexus IS III facelift 2 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise control main switch (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MAIN SWITCH
DISTANCE CONTROL SWITCH
ENGINE ROOM R/B 2 ASSEMBLY
FORWARD RECOGNITION CAMERA
GRN WIRE
IGB
INSTRUMENT PANEL J/B ASSEMBLY
LKSW
LT BLU WIRE
LT GRN WIRE
METER FUSE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
OUT
PNK WIRE
RADAR-IG FUSE
RED WIRE
RELAY ENERGIZED
RIGHT STEERING PAD SWITCH
SEMICONDUCTOR POWER INTEGRATION ECU ENGINE ROOM J/B 2 ASSEMBLY
SGND
SHIFT LOCK CONTROL ECU (TRANSMISSION FLOOR SHIFT ASSEMBLY)
SKID CONTROL BUZZER ASSEMBLY
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Cruise control circuit (2 of 3) -> CRUISE CONTROL MAIN SWITCH
