Lexus IS III facelift 2 (2020-2024) antenna cord sub-assembly 2 Wiring diagrams

This page contains all the electrical diagrams for the component. antenna cord sub-assembly 2, in which he is found in the car Lexus IS III facelift 2 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram antenna cord sub-assembly 2 (1 of 3)

Wiring diagram antenna cord sub-assembly 2 for Lexus IS III facelift 2 (2020-2024)

Get access

AM/FM MAIN ANTENNA ANTENNA CORD SUB-ASSEMBLY 2 BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DCM FUSE ENGINE ROOM R/B 2 ASSEMBLY FM SUB ANTENNA GPS GPSSLD GRN WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL J/B ASSEMBLY LT GRN WIRE MACC MCO- METER FUSE MIN NCA WIRE ORG/ WIRE PNK WIRE RADIO RECEIVER ASSEMBLY RED WIRE SGND SHIELD TEL TELEPHONE MICROPHONE ASSEMBLY TELEPHONE- MAIN GPS ANTENNA TELSLD USB USBS VMTF W/ TELEMATICS SYSTEM W/O NAVIGATION W/O TELEMATICS SYSTEM WHT WIRE

Go to component: -> Navigation circuit (4 of 7) -> ANTENNA CORD SUB-ASSEMBLY 2

Wiring diagram antenna cord sub-assembly 2 (2 of 3)

Wiring diagram antenna cord sub-assembly 2 for Lexus IS III facelift 2 (2020-2024)

Get access

AM/FM MAIN ANTENNA ANTENNA CORD SUB-ASSEMBLY 2 BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DCM FUSE ENGINE ROOM R/B 2 ASSEMBLY FM SUB ANTENNA GPS GPSSLD GRN WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL J/B ASSEMBLY LT GRN WIRE MACC MCO- METER FUSE MIN NCA WIRE ORG/ WIRE PNK WIRE RADIO RECEIVER ASSEMBLY RED WIRE SGND SHIELD TEL TELEPHONE MICROPHONE ASSEMBLY TELEPHONE- MAIN GPS ANTENNA TELSLD USB USBS VMTF W/ TELEMATICS SYSTEM W/O NAVIGATION W/O TELEMATICS SYSTEM WHT WIRE

Go to component: -> Radio circuit (4 of 7) -> ANTENNA CORD SUB-ASSEMBLY 2

Wiring diagram antenna cord sub-assembly 2 (3 of 3)

Wiring diagram antenna cord sub-assembly 2 for Lexus IS III facelift 2 (2020-2024)

Get access

AIR BAG SENSOR ASSEMBLY ANTENNA CORD SUB-ASSEMBLY 2 BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY BRN WIRE CANN CANP CERTIFICATION ECU COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DCM (TELEMATICS TRANSCEIVER) DCM FUSE ENGINE ROOM R/B ASSEMBLY 2 GPS GPSSLD GREEN IND GRN WIRE GSW HOT AT ALL TIMES IG+ DISPLAY DRIVER INSTRUMENT PANEL J/B ASSEMBLY LT BLU WIRE LT GRN WIRE MACC MAP LIGHT ASSEMBLY MCI- MCO- MCVD METER FUSE MIN MSCH MSCL MUTE NAVIGATION ECU ASSEMBLY NCA WIRE PNK WIRE PPL/ORG WIRE PPL/PNK WIRE RADIO RECEIVER ASSEMBLY RED WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT FRONT SPEAKER ASSEMBLY 2 RRID SGND SHIELD SHIELD USBS SIG SLP SLPD SOS SWITCH SPI+ SPO- STEREO COMPONENT AMPLIFIER ASSEMBLY TEL TELEPHONE MICROPHONE ASSEMBLY TELSLD TMUT USB USBG USBS USBV VIO WIRE VOR- VOT+ W/ LEXUS NAVIGATION SYSTEM W/O LEXUS NAVIGATION SYSTEM WHT WIRE YEL WIRE

Go to component: -> Telematics circuit -> ANTENNA CORD SUB-ASSEMBLY 2
