Trunk & fuel door release circuit for Lexus IS III (2013-2016)

Trunk & fuel door release circuit

Get access

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COURTESY CYLINDER FUEL LID FUEL LID W/ MOTOR LOCK ASSEMBLY (LEFT REAR OF VEHICLE) FUEL OPN FUSE GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT) LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT MAIN BODY ECU LKUL LPSW LT BLU WIRE LT GRN WIRE LUGGAGE LUGGAGE COMPARTMENT DOOR LOCK LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID) LUGGAGE COMPARTMENT DOOR OPENING CANCEL SWITCH ASSEMBLY LUGGAGE DOOR OPENING SWITCH ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH (CENTER REAR OF LUGGAGE COMPT LID) MPX-B FUSE PNK WIRE RED WIRE RIGHT COWL SIDE J/B (RIGHT END OF DASH) RIGHT MAIN BODY ECU SGND MPXB TKUL TR+ LGCY TSW BECU WHT WIRE WHT/BLK WIRE
