Car Wiring Diagrams for Rear sonar circuit for Lexus IS III (2013-2016)

13 14 CANL CANH COMPUTER DATA LINES SYSTEM 34 24 7 PNK WIRE 6 18 17 MPX+ MPX- COMPUTER DATA LINES SYSTEM 7 6 5 SET LSEL RSEL BKUP BLK WIRE BLU/RED WIRE BRN WIRE CLEARANCE SONAR IND CLEARANCE WARNING BUZZER 1 (UNDER CENTER OF DASH) CLEARANCE WARNING ECU (LEFT SIDE OF TRUNK) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DOME +B ENGINE CONTROL MODULE (ECM) GRN WIRE GRN/BLK WIRE GRY WIRE HOT AT ALL TIMES IG CBZ INPUT CIRCUIT LCD (MULTI) LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT FRONT ULTRASONIC SENSOR 1 (LEFT FRONT OF VEHICLE) LEFT MAIN BODY ECU LEFT REAR ULTRASONIC SENSOR 1 (LEFT CORNER OF REAR BUMPER) LEFT REAR ULTRASONIC SENSOR 2 (LEFT SIDE OF REAR BUMPER) LH-IG FUSE MICRO COMPUTER ORG/ WIRE PARK/ NEUTRAL POSITION SWITCH ASSEMBLY PARKING BRAKE SWITCH (TOP OF PARKING BRAKE LEVER) PKB IG ECU-IG RH FUSE PNK WIRE POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) RED WIRE RELAY RH-IG FUSE RIGHT COWL SIDE J/B (RIGHT END OF DASH) RIGHT FRONT ULTRASONIC SENSOR 1 (RIGHT FRONT OF VEHICLE) RIGHT MAIN BODY ECU RIGHT REAR ULTRASONIC SENSOR 1 (RIGHT CORNER OF REAR BUMPER) RIGHT REAR ULTRASONIC SENSOR 2 (RIGHT SIDE OF REAR BUMPER) SATELLITE SWITCH SET TRANSMISSION ASSEMBLY VIO WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE CLEARANCE WARNING ECU (LEFT END OF DASH) COMPUTER DATA LINES SYSTEM EF CBZ IG FUSE GRN WIRE GRY WIRE IG+ PNK WIRE INSTRUMENT PANEL J/B (LEFT END OF DASH) KD (CENTER OF DASH) LEFT FRONT CENTER ULTRASONIC SENSOR 1 (BEHIND LEFT CENTER FRONT OF BUMPER) LEFT FRONT ULTRASONIC SENSOR 1 (BEHIND LEFT CORNER OF FRONT BUMPER) LEFT REAR ULTRASONIC SENSOR 1 (LEFT CORNER OF REAR BUMPER) LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT CENTER ULTRASONIC SENSOR 1 (BEHIND RIGHT CENTER FRONT OF BUMPER) RIGHT REAR CENTER ULTRASONIC SENSOR 1 (RIGHT CENTER OF REAR BUMPER) RIGHT REAR ULTRASONIC SENSOR 1 (RIGHT CORNER OF REAR BUMPER) VIO WIRE WHT WIRE

13 14 CANL CANH 29 30 CANH CANL BLK WIRE BLU WIRE BRN WIRE CAN I/F CLEARANCE WARNING BUZZER 1 (LEFT SIDE OF DASH) COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DIODE (PARK/NEUTRAL POSITION SWITCH ASSEMBLY) (BEHIND LEFT SIDE OF DASH) DISPLAY DRIVER ECM (LEFT FRONT OF ENGINE COMPT) ECU-ACC FUSE FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (LEFT END OF DASH) J/C 1 (LEFT SIDE OF ENGINE COMPT) J/C 4 (LEFT SIDE OF ENGINE COMPT) KC (RIGHT KICK PANEL) LED DRIVER LEFT REAR CENTER ULTRASONIC SENSOR 1 (LEFT CENTER OF REAR BUMPER) LT GRN WIRE METER FUSE ORG/ WIRE PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) RED WIRE RELAY RELAY ENERGIZED RIGHT FRONT ULTRASONIC SENSOR 1 (BEHIND RIGHT CORNER OF FRONT BUMPER) TELLTALES VIO WIRE
