Data link connector circuit for Lexus IS III (2013-2016)
Data link connector circuit
BLU WIRE
BRAKE ACTUATOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
BRN WIRE
CG SG CANH SIL
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3 (BEHIND LOWER LEFT SIDE OF DASH)
DCM TELEMATICS TRANSCEIVER (RIGHT SIDE OF DASH)
DIA
ECM (ENGINE CONTROL MODULE) (LEFT FRONT
GRN WIRE
GRN/BLK WIRE
HIGH/LOW BUS CIRCUIT
HOT AT ALL TIMES
LEFT COWL SIDE J/B (LEFT END OF DASH)
LT BLU WIRE
NETWORK GATEWAY ECU (RIGHT END OF DASH)
OBD FUSE
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
OF ENGINE COMPT)
RED WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT MAIN BODY ECU
SIL
TAC
TS TC CANL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
