Lexus IS III (2013-2016) upper side tonneau cover switch (right side Wiring diagram
This page shows the only wiring diagram for the component.upper side tonneau cover switch (right side, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram upper side tonneau cover switch (right side (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 SMR+ SMR-
1 2 3 4 5 6 7 8 9 10 LCL+
10 11 PNK WIRE
BACK WINDOW LOCK ASSEMBLY (LEFT REAR SIDE OF ROOF)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FLS (+)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IG SGND ECUB LCLS LCLP LCLF LCLH
LCL
LEFT ROOF PANEL STRENGTH SUB-ASSEMBLY 2
LH LGG FUSE
LH LGG LCK FUSE
LML-
LPLB
LPLE
LT GRN WIRE
LUGGAGE ROOM R/B (LEFT FRONT OF TRUNK)
ORG/ WIRE
P-TRAY SIDE FUSE
PACKAGE TRAY TRIM COVER) (RIGHT UPPER REAR SIDE OF TRUNK)
PACKAGE TRAY TRIM HINGE 1 (RIGHT REAR OF TRUNK)
PACKAGE TRAY TRIM HINGE 2 (LEFT REAR OF TRUNK)
PNK WIRE
QWL RCL LOL TL 1
RED WIRE
SLIDING ROOF CONTROL ECU (CENTER FRONT OF TRUNK)
SML+ SML-
UPPER SIDE TONNEAU COVER SWITCH (RIGHT SIDE
VIO WIRE
WDN WUP RPLE LPL RPL RPLB LCT PNK WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit (3 of 3) -> UPPER SIDE TONNEAU COVER SWITCH (RIGHT SIDE
