Lexus IS III (2013-2016) stop/ tail marker ind ind Wiring diagram

14 13 CANH CANL 31 22 2 STPO 8 12 13 IGSW BACKUP BACKUP LAMPS CIRCUIT BLK WIRE BLK/ WHT WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRAKE ACTUATOR ASSEMBLY (LEFT REAR OF ENGINE COMPT) BRK-LP RELAY BRN WIRE COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (LEFT FRONT OF ENGINE COMPT) ENGINE ROOM R/B 3 (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT) LH J/B- AM FUSE HOT IN ON OR START IGN FUSE JUNCTION CONNECTOR LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT REAR COMBINATION LIGHT ASSEMBLY LT GRN WIRE MARKER IND NOISE FILTER (STOP LIGHT) (LEFT SIDE OF TRUNK) PNK 8 6 4 2 OUT +B GND STP WIRE POWER SOURCE CONTROL ECU RED WIRE RED/BLK WIRE RED/WHT WIRE RIGHT COWL RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT REAR COMBINATION LIGHT ASSEMBLY SHIFT LOCK CONTROL ECU STOP CENTER LIGHT SET STOP LIGHT CONTROL RELAY (BEHIND CENTER OF DASH) STOP LIGHT SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) STOP SW FUSE SIDE J/B (RIGHT END OF DASH) STOP/ TAIL IND STOP/ TAIL MARKER IND IND STP TL TAIL FUSE TAIL IND TAIL RELAY TRANSMISSION CONTROL ECU (LEFT SIDE OF ENGINE COMPT) TRN+ TURN TURN BACKUP WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE YEL WIRE
