Lexus IS III (2013-2016) solar sensor automatic light control sensor (behind left side of dash) wiring diagram
This page shows the only wiring diagram for the component.solar sensor automatic light control sensor (behind left side of dash), which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
solar sensor automatic light control sensor (behind left side of dash) wiring diagram (1 of 1)
A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
A/C FUSE
A/C PRESSURE SENSOR (LEFT SIDE OF RADIATOR)
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLW
BRN WIRE
BRN/RED WIRE
CLTB
CLTE
CLTS
COMPRESSOR ASSEMBLY
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DGS
DGS TSD TAM SG SG-2 SG-6
ECU-IG LH FUSE
FLOW CONTROL
FRONT BLOWER FAN MOTOR (UNDER LOWER
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ LH-IG 1 RELAY ENERGIZED
HOT W/ LH-IG 2 RELAY ENERGIZED
JUNCTION CONNECTOR
LEFT COWL SIDE J/B (LEFT END OF DASH)
LH-IG FUSE
LT GRN WIRE
MHTR RDFG
MPX+ MPX-
ORG/ WIRE
PNK WIRE
PRE TSP PNK WIRE
RED WIRE
RIGHT MAIN BODY ECU (RIGHT COWL SIDE JUNCTION BLOCK)
SG-1 GND IG+
SMOG VENTILATION SENSOR (FRONT OF RADIATOR)
SOL +
SOLAR SENSOR AUTOMATIC LIGHT CONTROL SENSOR (BEHIND LEFT SIDE OF DASH)
TSL
TSR
VALVE
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
