Lexus IS III (2013-2016) security indicator light Wiring diagrams
This page contains all the electrical diagrams for the component. security indicator light, in which he is found in the car Lexus IS III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram security indicator light (1 of 2)
2.5L HID W/ HEADLIGHT CLEANER
BATB
BLU WIRE
BZR
COMPUTER DATA LINES SYSTEM
DCTY
DIODE (LUGGAGE COMPARTMENT LAMP) (LEFT FRONT OF TRUNK)
ECU-IG RH FUSE
EXCEPT 2.5L HID W/ HEADLIGHT CLEANER
FR DOOR RH FUSE
FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IND
INTEGRATION CONTROL, PANEL ASSEMBLY LP
J/C
KEY LOCK
KEY UNLOCK
KUL
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (LEFT FRONT "B" PILLAR)
LEFT FRONT DOOR LOCK ASSEMBLY (DRIVER'S DOOR)
LGCY
LSW
LSWP
LT BLU WIRE
LT GRN WIRE
MULTI- DISPLAY ASSEMBLY SECU
ORG/ WIRE
PCTY
POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
RED/WHT WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (RIGHT FRONT "B" PILLAR)
RIGHT FRONT DOOR LOCK ASSEMBLY (FRONT PASSENGER'S DOOR)
RIGHT MAIN BODY ECU
SECURITY HORN ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
SECURITY INDICATOR LIGHT
TI, TE FUSE
UNLOCK DETECTION
VIO WIRE
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (INSIDE LEFT FRONT WHEELWELL)
Go to component -> Anti-theft circuit (1 of 5) -> SECURITY INDICATOR LIGHT
