Lexus IS III (2013-2016) on hook disp Wiring diagram
This page shows the only wiring diagram for the component.on hook disp, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on hook disp (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 MUTE L- L+ R- R+
1 2 3 4 5 6 7 8 9 10 FL+ FR+
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B 1 (RIGHT REAR
FL+ FR+
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INPUT CIRCUIT
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT FRONT SPEAKER ASSEMBLY 2, 3 (FRONT SPEAKER ASSEMBLY 3)
LEFT REAR SPEAKER ASSEMBLY
LEFT STEERING PAD SWITCH
LT BLU WIRE
MICRO COMPUTER
MODE
MSSL
OF ENGINE COMPT)
OFF HOOK DISP
ON HOOK DISP
ORG/ WIRE
PNK TMUT WIRE
PNK WIRE
RAD 2 FUSE
RED WIRE
RED/BLU WIRE
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT FRONT SPEAKER ASSEMBLY 2, 3 (FRONT SPEAKER ASSEMBLY 3)
RIGHT REAR SPEAKER ASSEMBLY
RIGHT STEERING PAD SWITCH
SEEK
SPIRAL CABLE (UNDER STEERING WHEEL)
STEERING PAD SWITCH ASSEMBLY
STEREO COMPONENT AMPLIFIER (RIGHT SIDE OF TRUNK)
TX- TX+
VIO WIRE
VOICE
VOL (-)
W/ SAFETY CONNECT W/O SAFETY CONNECT
WFL+ RL+ RR+ PNK PNK WIRE
WFL- WFR- WFR+ RL- RR- PNK WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, without navigation (3 of 3) -> ON HOOK DISP
