Lexus IS III (2013-2016) integrated control, panel assembly secu security indicator light Wiring diagrams
This page contains all the electrical diagrams for the component. integrated control, panel assembly secu security indicator light, in which he is found in the car Lexus IS III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram integrated control, panel assembly secu security indicator light (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
BZR
COMPT)
COURTESY
COURTESY SWITCH (LEFT "C" PILLAR)
CTY
DCTY
DOME LIGHT
DOME LIGHT STOP LIGHT ASSEMBLY
DOOR
GRN WIRE
ILLB
IND
INTEGRATED CONTROL, PANEL ASSEMBLY SECU SECURITY INDICATOR LIGHT
LCTY
LEFT FRONT DOOR COURTESY SWITCH (LEFT "B" PILLAR)
LILL
LOCK
LT GRN WIRE
LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID)
MULTI- DISPLAY ASSEMBLY
ORG/ WIRE
OVERHEAD MODULE (CENTER FRONT OF ROOF)
PCTY
RCTY
RED WIRE
RED/WHT WIRE
RIGHT COWL SIDE J/B (RIGHT
RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY
RIGHT FRONT DOOR COURTESY SWITCH (RIGHT "B" PILLAR)
RIGHT MAIN BODY ECU END OF DASH)
RIGHT REAR DOOR COURTESY SWITCH (RIGHT "C" PILLAR)
SECU SECURITY INDICATOR LIGHT
SECURITY HORN ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
UN LOCK
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (LEFT SIDE OF ENGINE COMPT)
YEL WIRE
Go to component -> Anti-theft circuit (2 of 7) -> INTEGRATED CONTROL, PANEL ASSEMBLY SECU SECURITY INDICATOR LIGHT
