Lexus IS III (2013-2016) gnd bdcy Wiring diagrams
This page contains all the electrical diagrams for the component. gnd bdcy, in which he is found in the car Lexus IS III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram gnd bdcy (1 of 2)
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOME FUSE
ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT)
FOOT LIGHT
GND BDCY
GRN WIRE
GRY WIRE
HEAD LP RELAY
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
LCTY
LEFT COWL SIDE J/B (LEFT LEFT MAIN BODY ECU END OF DASH)
LEFT OUTER REAR VIEW MIRROR MLP+
LGCY
LKUL LPSW
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT DOOR LOCK CYLINDER
LUGGAGE ELECTRICAL KEY SWITCH (CENTER REAR OF LUGGAGE COMPT LID)
MAIN FUSE
MLP
PNK WIRE
RED/WHT WIRE
RIGHT OUTER REAR VIEW MIRROR MLP+
SGND
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-theft circuit (3 of 7) -> GND BDCY
Wiring diagram gnd bdcy (2 of 2)
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOME FUSE
ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT)
FOOT LIGHT
GND BDCY
GRN WIRE
GRY WIRE
HEAD LP RELAY
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
LCTY
LEFT COWL SIDE J/B (LEFT LEFT MAIN BODY ECU END OF DASH)
LEFT OUTER REAR VIEW MIRROR MLP+
LGCY
LKUL LPSW
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT DOOR LOCK CYLINDER
LUGGAGE ELECTRICAL KEY SWITCH (CENTER REAR OF LUGGAGE COMPT LID)
MAIN FUSE
MLP
PNK WIRE
RED/WHT WIRE
RIGHT OUTER REAR VIEW MIRROR MLP+
SGND
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power door locks circuit (3 of 7) -> GND BDCY
