Lexus IS III (2013-2016) ecub ig cann Wiring diagram
This page shows the only wiring diagram for the component.ecub ig cann, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ecub ig cann (1 of 1)
1 2 3 4 5 6 7 GND +B CANP
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECUB IG CANN
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL J/B TI, TE (LEFT END FUSE OF DASH)
KA (LEFT KICK PANEL)
KD (CENTER OF DASH)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (LEFT FRONT DOOR)
LEFT SEAT MEMORY SWITCH
LT BLU WIRE
LT GRN WIRE
MM CANN CANP GND
MMRY
MPX-B 1 FUSE
MSW
MSW TEM- TIM-
MULTIPLEX TILT, TELESCOPIC ECU (ON STEERING COLUMN)
ORG/ WIRE
PNK WIRE
QA (LEFT "B" PILLAR)
RED WIRE
RELAY ENERGIZED
SET-
TELESCO SHORTEN
TELESCO STRETCH
TELESCOPIC MOTOR
TEM
TES
TILT DOWN
TILT MOTOR
TILT STEERING GEAR W/ MOTOR (AT STEERING COLUMN)
TILT UP
TILT, TELESCOPIC SWITCH
TIM
TIS
VC TEM+ TIM+
VCE
VCI
VCI VCE TES TIS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Memory power tilt & power telescopic circuit -> ECUB IG CANN
