Lexus IS III (2013-2016) compressor assembly w/ magnet clutch Wiring diagrams
This page contains all the electrical diagrams for the component. compressor assembly w/ magnet clutch, in which he is found in the car Lexus IS III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram compressor assembly w/ magnet clutch (1 of 2)
A/C AMPLIFIER (CENTER OF DASH)
A/C BLOWER ASSEMBLY
A/C COMP FUSE
A/C COMP RELAY
A/C EVAPORATOR TEMPERATURE SENSOR
BBUS
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
BUS -
BUS G
COLOR (RED) WIRE
COMPRESSOR ASSEMBLY W/ MAGNET CLUTCH
CONNECTOR HOUSING
CONNECTOR HOUSING COLOR (BLACK)
CONNECTOR HOUSING COLOR (BLUE)
CONNECTOR HOUSING COLOR (GREEN)
CONNECTOR HOUSING COLOR (NATURAL)
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2
DAMPER SERVO MOTOR (AIR INLET)
DAMPER SERVO MOTOR (AIR MIX DRIVER SIDE)
DAMPER SERVO MOTOR (AIR MIX FRONT PASSENGER SIDE)
DAMPER SERVO MOTOR (AIR VENT MODE)
DAMPER SERVO MOTOR (COOL AIR BYPASS)
ENGINE COMPT)
ENGINE ROOM R/B 2 (LEFT SIDE OF
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FLOW CONTROL VALVE
GRY WIRE
HOT AT ALL TIMES
LOCK SENSOR
MAGNETIC CLUTCH
RED WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> COMPRESSOR ASSEMBLY W/ MAGNET CLUTCH
Wiring diagram compressor assembly w/ magnet clutch (2 of 2)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
BRN WIRE
CANISTER PUMP MODULE
COMPRESSOR ASSEMBLY W/ MAGNET CLUTCH
CRANK POSITION SENSOR SHIELD
DATA LINK CONNECTOR (DLC) 3
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) SHIELD
ENGINE IGNITION CONTROL COIL 5 MODULE (ECM)
ENGINE OIL LEVEL SENSOR
FUEL INJECTOR (DIRECT INJECTION 1) SHIELD
FUEL INJECTOR (DIRECT INJECTION 2) SHIELD
FUEL INJECTOR (DIRECT INJECTION 4) SHIELD
FUEL INJECTOR (DIRECT INJECTION 6) SHIELD
IGNITION IGNITION COIL 1 COIL 3
IGNITION IGNITION COIL 6 COIL 4 (3.5L) (3.5L)
INJECTOR DRIVER SHIELD
JUNCTION
JUNCTION CONNECTOR
KNOCK CONTROL SENSOR (BANK 1) SHIELD
KNOCK CONTROL SENSOR (BANK 2) SHIELD
OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
POWER STEERING MOTOR SHIELD
SHIELD
SPILL CONTROL VALVE SHIELD
SPIRAL CABLE (UNDER STEERING WHEEL)
STEREO COMPONENT AMPLIFIER
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 6) -> COMPRESSOR ASSEMBLY W/ MAGNET CLUTCH
