Lexus IS III (2013-2016) back sonar or clearance sonar switch assembly Wiring diagram
This page shows the only wiring diagram for the component.back sonar or clearance sonar switch assembly, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back sonar or clearance sonar switch assembly (1 of 1)
BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
BLK WIRE
BLU WIRE
BRN WIRE
CLEARANCE WARNING ECU (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
EF CBZ IG
FUSE
GRN WIRE
GRY WIRE
IG+ PNK WIRE
INSTRUMENT PANEL J/B (LEFT END OF DASH)
KD (CENTER OF DASH)
LEFT FRONT CENTER ULTRASONIC SENSOR 1 (BEHIND LEFT CENTER FRONT OF BUMPER)
LEFT FRONT ULTRASONIC SENSOR 1 (BEHIND LEFT CORNER OF FRONT BUMPER)
LEFT REAR ULTRASONIC SENSOR 1 (LEFT CORNER OF REAR BUMPER)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FRONT CENTER ULTRASONIC SENSOR 1 (BEHIND RIGHT CENTER FRONT OF BUMPER)
RIGHT REAR CENTER ULTRASONIC SENSOR 1 (RIGHT CENTER OF REAR BUMPER)
RIGHT REAR ULTRASONIC SENSOR 1 (RIGHT CORNER OF REAR BUMPER)
VIO WIRE
WHT WIRE
Go to component -> Rear sonar circuit (1 of 2) -> BACK SONAR OR CLEARANCE SONAR SWITCH ASSEMBLY
