Lexus IS III (2013-2016) all dr lock relay Wiring diagram
This page shows the only wiring diagram for the component.all dr lock relay, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram all dr lock relay (1 of 1)
ALL DR LOCK RELAY
BKUP LP RELAY
BLU WIRE
BRN WIRE
CERTIFICATION ECU
COMBINATION METER ASSEMBLY
D DR UNLOCK RELAY
DATA LINK CONNECTOR 3
FUEL LOCK RELAY
HEADLIGHT DIMMER SWITCH ASSEMBLY
KA (LEFT KICK PANEL)
KC (RIGHT END OF DASH)
L/D DR P/OUTLET UNLOCK RELAY RELAY
LEFT VISOR ASSEMBLY
LUGGAGE DOOR OPENING SWITCH ASSEMBLY
MAIN BODY ECU
MAP LIGHT ASSEMBLY
RELAY 2
RELAY 3
REMOTE CLOCK OPERATION ASSEMBLY SWITCH
SLIDING ROOF CONTROL ECU (SLIDING ROOF RIGHT GEAR SUB VISOR ASSEMBLY) ASSEMBLY
SPIRAL CABLE W/ SENSOR SUB ASSEMBLY (STEERING COLUMN)
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY (UNDER STEERING WHEEL)
STEERING LOCK ACTUATOR ASSEMBLY
STEERING PAD RADIO SWITCH RECEIVER ASSEMBLY ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
STEERING WHEEL HEATER CONTROL ASSEMBLY
TIRE PRESSURE MONITOR INITIATOR OPTION DRIVER CONNECTOR
TIRE PRESSURE WARNING RESET SWITCH (PRESSURE WARNING SWITCH 1)
TRUNK OPN RELAY 1 RELAY RELAY
W/ FRONT FOG LIGHT
W/ NAVIGATION SYSTEM W/O NAVIGATION SYSTEM
W/ NETWORK GATEWAY ECU
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YAW RATE SENSOR
Go to component -> Ground distribution circuit (3 of 5) -> ALL DR LOCK RELAY
