Lexus IS III (2013-2016) air bag sensor seat position Wiring diagram
This page shows the only wiring diagram for the component.air bag sensor seat position, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag sensor seat position (1 of 1)
-SR -SL +SR +SL
AIR BAG SENSOR SEAT POSITION
BBL+
BBL- BBL+
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BUCKLE SWITCH
CENTER AIR BAG SENSOR (UNDER REAR OF CENTER CONSOLE)
COMPUTER DATA LINES SYSTEM
DCM TELEMATICS TRANSCEIVER (RIGHT SIDE OF DASH)
DK DK
ECU-IG RH FUSE
GRN WIRE
GRY WIRE
GSW
HOT AT ALL TIMES
IGN FUSE GAUGE FUSE
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY (LEFT ROOF RAIL)
LEFT FRONT PRETENSIONER (BASE OF LEFT "B" PILLAR)
LEFT FRONT SEAT INNER BELT ASSEMBLY (IN DRIVER'S SEAT BELT BUCKLE ASSEMBLY)
LEFT FRONT SIDE AIR BAG SENSOR (LEFT "B" PILLAR)
LEFT FRONT SIDE AIR BAG SQUIB (LEFT SIDE OF DRIVER'S SEAT BACK)
LEFT REAR AIR BAG SENSOR (LEFT "C" PILLAR) BCL- BCL+
LEFT REAR PRETENSIONER (LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
P- P+ D+ D-
PNK 1 2 3 4 5 6 7 8 9 WIRE
PNK COMPUTER DATA LINES SYSTEM CAN L PAON WIRE
PNK WIRE
RED WIRE
RELAY
RELAY ENERGIZED
RIGHT COWL SIDE J/B (RIGHT END END DASH)
RIGHT MAIN BODY ECU
SIL P-AB GSW PK+ PK-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (1 of 3) -> AIR BAG SENSOR SEAT POSITION
