Lexus IS III (2013-2016) 30 31 computer mpx+ mpx- data lines system Wiring diagrams
This page contains all the electrical diagrams for the component. 30 31 computer mpx+ mpx- data lines system, in which he is found in the car Lexus IS III (2013-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 30 31 computer mpx+ mpx- data lines system (1 of 2)
1 2 3 +B SI GND
13 14 CANL CANH
13 26 38 26 49 48 PRE
30 31 COMPUTER MPX+ MPX- DATA LINES SYSTEM
A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
A/C PRESSURE SENSOR (LEFT SIDE OF RADIATOR)
BLK WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLING FAN ECU (BEHIND LEFT RADIATOR COOLING FAN MOTOR)
COOLING FAN ECU 2 (BEHIND RIGHT RADIATOR COOLING FAN MOTOR)
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPT)
COOLING FAN MOTOR 2 (RIGHT FRONT OF ENGINE COMPT)
ECM (ENGINE CONTROL MODULE) (LEFT FRONT OF ENGINE COMPT)
EFI ENGINE COOLANT TEMPERATURE SENSOR (TOP OF ENGINE)
ENGINE ROOM
FAN 1 FAN 2 J/B 1 FUSE FUSE (RIGHT REAR OF ENGINE COMPT)
FAN RELAY 1
FAN RELAY 2
GRN/YEL WIRE
HOT AT ALL TIMES
HOT W/ LH-IG 1 RELAY ENERGIZED LEFT COWL SIDE J/B LH-IG (LEFT FUSE END OF DASH)
JUNCTION CONNECTOR
PNK SG-2 WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RFC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Cooling fan circuit -> 30 31 COMPUTER MPX+ MPX- DATA LINES SYSTEM
Wiring diagram 30 31 computer mpx+ mpx- data lines system (2 of 2)
1 2 3 4 5 6 7 8 9 IG
30 31 COMPUTER MPX+ MPX- DATA LINES SYSTEM
A/C AMPLIFIER (BEHIND RIGHT SIDE OF DASH)
ANFR
ANRL
BLK WIRE
BRN WIRE
COMBINATION INT INT METER ASSEMBLY
COMPUTER DATA LINES
COMPUTER DATA LINES GTX+ GTX- SYSTEM
COMPUTER DATA LINES SYSTEM
DOME+B
ECU-IG LH FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
INPUT CIRCUIT
LCD (MULTI)
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT REAR TIRE PRESSURE WARNING ANTENNA (LEFT REAR WHEELWELL)
LSEL RSEL SET
LT BLU WIRE
LT GRN WIRE
MICRO COMPUTER
MPX+ MPX-
MPX-B FUSE
NCA WIRE
NETWORK GATEWAY ECU (RIGHT END OF DASH)
ORG/ WIRE
PNK CLSW IDSW GND WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
POWER SUPPLY CIRCUIT
RED WIRE
RELAY
RELAY ENERGIZED
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT FRONT TIRE PRESSURE WARNING ANTENNA (RIGHT FRONT WHEELWELL)
SATELLITE RSEL LSFT SET SWITCH SET
SYSTEM
TIRE PRESSURE IND MASTER IND
TIRE PRESSURE WARNING ECU, RECEIVER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Tire pressure monitoring circuit -> 30 31 COMPUTER MPX+ MPX- DATA LINES SYSTEM
