Lexus IS III (2013-2016) 14 11 trly Wiring diagram

14 11 TRLY 14 13 CANH CANL 20 19 21 CLTS CLTB CLTE 22 8 12 TAIL 32 31 30 IG BECU 4 1 2 CLTS CLTB CLTE ACAN AUTO DRL OFF OFF TAIL HEAD AUTOMATIC LIGHT CONTROL SENSOR (RIGHT SIDE OF DASH, AT BASE OF WINDSHIELD) BLK WIRE BLU WIRE CANADA COMPUTER DATA LINES SYSTEM CONTROL DOME LIGHT SWITCH ECU-ACC FUSE ECU-B FUSE ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT) FUSE GLOVE BOX LIGHT GRN WIRE GRY WIRE HEAD HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES ILLB INSTRUMENT PANEL J/B (LEFT END OF DASH) J/B LH-AM FUSE KA (LEFT KICK PANEL) KC (RIGHT KICK PANEL) LIGHT CONTROL SWITCH LILL LT GRN WIRE MAIN BODY ECU (IN INSTRUMENT PANEL J/B) MAP LIGHT ASSEMBLY MAP LIGHT SWITCH ORG/ WIRE PANEL FUSE PNK WIRE RED WIRE RELAY RELAY ENERGIZED RILL RLMP SLIDING ROOF SOLAR SENSOR SPOT LIGHT ASSEMBLY SWITCH TAIL AUTO OFF DRL OFF HEAD TAIL RELAY USA WHT WIRE WHT/BLK WIRE YEL WIRE
