Lexus IS III (2013-2016) 1 2 bzp bzn Wiring diagram
This page shows the only wiring diagram for the component.1 2 bzp bzn, which is found in the car Lexus IS III (2013-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 bzp bzn (1 of 1)
1 2 BZP BZN
29 30 CANH CANL
5 4 EL ER PNK WIRE
BDSL
BDSR
BIND
BLB
BLGD
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRB
BRGD
BRN WIRE
BSL+
BSR+
BSSW
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
FUSE
GRN WIRE
GRY WIRE
GRY/RED WIRE
HEADLAMP DIMMER SWITCH ASSEMBLY
INDICATOR
INSTRUMENT PANEL J/B
J/C 6 (RIGHT FRONT DOOR)
J/C 7 (LEFT FRONT DOOR)
LED DRIVER
LEFT BLIND
LEFT BLIND SPOT MONITOR MAIN SWITCH
LEFT BLIND SPOT MONITOR SENSOR (LEFT CORNER OF REAR BUMPER)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (LEFT FRONT DOOR)
LEFT OUTER REARVIEW MIRROR ASSEMBLY
LT GRN WIRE
METER ASSEMBLY FUSE (LEFT END OF DASH)
OMIL
OMIR
ORG/ WIRE
PNK WIRE
QA (LEFT "B" PILLAR)
QB (LEFT SIDE OF TRUNK)
REAR CROSS TRAFFIC ALERT BUZZER (UNDER CENTER OF REAR PACKAGE SHELF)
RED WIRE
RELAY ENERGIZED
RIGHT
RIGHT BLIND
RIGHT BLIND SPOT MONITOR SENSOR (RIGHT CORNER OF REAR BUMPER)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (RIGHT FRONT DOOR)
RIGHT OUTER REARVIEW MIRROR ASSEMBLY
SPOT MONITOR
TELLTALES
W/ MEMORY W/O MEMORY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER QA SWITCH ASSEMBLY (LEFT "B" PILLAR)
YEL WIRE
Go to component -> Blind spot monitoring circuit -> 1 2 BZP BZN
