Car Wiring Diagrams for Steering column circuit for Lexus IS II facelift (2008-2010)

1 2 3 4 5 6 7 GND SGND IGE 32 26 30 SLR+ SLP BLK WIRE ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT) GRN WIRE HOT AT ALL TIMES ID CODE BOX (BEHIND CENTER OF DASH) IGN FUSE JUNCTION LIN LT GRN WIRE POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH) RED WIRE RELAY ENERGIZED RIGHT COWL SIDE J/B (RIGHT END OF DASH) STEERING LOCK ACTUATOR (STEERING COLUMN) STR LOCK FUSE VIO WIRE WHT WIRE WHT/BLK WIRE
