Lexus IS II facelift (2008-2010) overhead module Wiring diagram
This page shows the only wiring diagram for the component.overhead module, which is found in the car Lexus IS II facelift (2008-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead module (1 of 1)
CENTER AIR BAG SENSOR ASSEMBLY
CIGARETTE LIGHTER ASSEMBLY
COMBINATION METER ASSEMBLY
DEFOG NOISE RELAY FILTER
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
ENGINE SWITCH
FAN RELAY 1
FAN RELAY 2
ID CODE BOX
JUNCTION
LEFT VISOR ASSEMBLY
LUGGAGE COMPARTMENT DOOR OPENING CANCEL SWITCH ASSEMBLY
LUGGAGE DOOR OPENING SWITCH ASSEMBLY
OVERHEAD MODULE
POWER SOURCE CONTROL ECU
POWER TILT MOTOR
PWR POINT RELAY RELAY
RELAY
RIGHT COWL SIDE J/B
RIGHT END OF DASH)
RIGHT MAIN BODY ECU
RIGHT VISOR ASSEMBLY
SKID CONTROL ECU ASSEMBLY
STARTER RELAY
STEERING LOCK ACTUATOR ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 7) -> OVERHEAD MODULE
