Power seats circuit for Lexus IS II facelift 2 (2010-2016)

BRN WIRE FR S/ HTR LH FUSE FUSE GRN WIRE HOT AT ALL TIMES HOT W/ LH-IG 2 RELAY ENERGIZED HOT W/ RH-IG 1 RELAY ENERGIZED FR S/ HTR RH JUNCTION JUNCTION CONNECTOR LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT SEAT HEATER CONTROL SUB-ASSEMBLY (UNDER DRIVER'S SEAT) LT BLU WIRE ORG/ WIRE PANEL FUSE PNK WIRE RED WIRE RH-IG FUSE RIGHT COWL SIDE J/B (RIGHT END OF DASH) RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY (UNDER RIGHT FRONT SEAT) SEAT BACK) SEAT CUSHION) SEAT HEATER CONTROL SEAT HEATER SWITCH SWL SWR TAIL RELAY THERMISTOR THL THR+ VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
