Lexus IS II facelift 2 (2010-2016) pnk out Wiring diagram
This page shows the only wiring diagram for the component.pnk out, which is found in the car Lexus IS II facelift 2 (2010-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk out (1 of 1)
31 22 2 STPO
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE ACTUATOR ASSEMBLY (LEFT REAR CORNER OF ENGINE COMPT)
BRK-LP RELAY
BRN WIRE
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES
HOT IN ON OR START
IND
LAMP
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LH J/B-AM FUSE
LH-IG FUSE
PNK OUT WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (RIGHT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE)
STOP IND
STOP LAMP CONTROL RELAY (LEFT SIDE OF DASH)
STOP LAMP SWITCH (LEFT SIDE OF DASH)
STOP SW FUSE
STOP/ MARKER IND
STOP/TAIL
TAIL FUSE
TAIL IND
TAIL RELAY
TURN
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (4 of 4) -> PNK OUT WIRE
