Lexus IS II facelift 2 (2010-2016) computer data lines (left system kick panel) wiring diagram
This page shows the only wiring diagram for the component.computer data lines (left system kick panel), which is found in the car Lexus IS II facelift 2 (2010-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
computer data lines (left system kick panel) wiring diagram (1 of 1)
BLU WIRE
BRN WIRE
COMPUTER DATA LINES (LEFT SYSTEM KICK PANEL)
FLS (+)
FR WIP FUSE
GRN/RED WIRE
GRY WIRE
HOT IN ON OR START
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LH-IG LEFT MAIN BODY ECU FUSE
LT GRN WIRE
MPXB
PNK WIRE
RED WIRE
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
SGND
SLIDING ROOF CONTROL ECU (CENTER FRONT OF TRUNK)
TRNL
TRNR
TURN
TURN SIGNAL FLASHER (LEFT CENTER OF DASH)
TURN SIGNAL RELAY (LEFT CENTER OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WIG
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 4) -> COMPUTER DATA LINES (LEFT SYSTEM KICK PANEL)
