Lexus IS II (2005-2008) shift illum- ination Wiring diagram
This page shows the only wiring diagram for the component.shift illum- ination, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram shift illum- ination (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
DOME FUSE
DOME LAMP
DOOR
ENGINE ROOM 1 R/B (RIGHT REAR OF ENGINE COMPT)
FSPT
GRN WIRE
HOT AT ALL TIMES
LEFT FOOT LAMP
LEFT FRONT MAP LAMP
LEFT REAR MAP LAMP
LEFT VANITY LAMP
LEFT VANITY LAMP SWITCH
ORG/ WIRE
OVERHEAD J/B (ON FRONT CENTER OF ROOF)
PNK WIRE
RED WIRE
RIGHT COWL SIDE J/B (AT RIGHT END OF DASH)
RIGHT FOOT LAMP
RIGHT FRONT MAP LAMP
RIGHT FRONT MAP LAMP LEFT FRONT MAP LAMP
RIGHT REAR MAP LAMP
RIGHT VANITY LAMP
RIGHT VANITY LAMP SWITCH
ROOM LAMP
SHIFT ILLUM- INATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> SHIFT ILLUM- INATION
