Lexus IS II (2005-2008) right outer rear view mirror foot lamp Wiring diagram
This page shows the only wiring diagram for the component.right outer rear view mirror foot lamp, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right outer rear view mirror foot lamp (1 of 1)
BLK WIRE
BLU WIRE
BODY COMPUTER
BODY ECU
BRN WIRE
DCTY
DCYL
FUSE
GRN WIRE
HOT AT ALL TIMES
LCTY
LEFT COWL SIDE J/B (AT LEFT END OF DASH)
LEFT FRONT DOOR COURTESY LAMP
LEFT FRONT DOOR COURTESY SWITCH
LEFT OUTER REAR VIEW MIRROR FOOT LAMP
LEFT OUTER SCUFF LAMP
LEFT REAR DOOR COURTESY SWITCH
LGCY
LT GRN WIRE
LUGGAGE DOOR LOCK ASSEMBLY
LUGGAGE ROOM LAMP
LUGGAGE ROOM LAMP DIODE
LUGGAGE ROOM LAMP NOISE FILTER
ORG/ WIRE
PARKING BRAKE SWITCH (M/T)
PCTY
PCYL
PNK WIRE
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
POWER SWITCH
RCTY
RCTY LGCY ILE BDCY
RED WIRE
RIGHT COWL SIDE J/B (AT RIGHT END OF DASH)
RIGHT FRONT DOOR COURTESY LAMP
RIGHT FRONT DOOR COURTESY SWITCH
RIGHT OUTER REAR VIEW MIRROR FOOT LAMP
RIGHT OUTER SCUFF LAMP
RIGHT REAR DOOR COURTESY SWITCH
VIO WIRE
W/ MEMORY W/O MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> RIGHT OUTER REAR VIEW MIRROR FOOT LAMP
