Lexus IS II (2005-2008) right outer rear mirror Wiring diagram
This page shows the only wiring diagram for the component.right outer rear mirror, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right outer rear mirror (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
COWL SIDE J/B RIGHT (AT RIGHT END OF DASH)
DEFOGGER SYSTEM
DOWN UP
EC+
EC+ MF
EC+ MV M+ MF MR
ELECTRO- CHROMIC MIRROR CIRCUIT
FUSE
GRN WIRE
HOT IN ACC OR ON
LEFT OUTER REAR MIRROR
LEFT RIGHT
LT GRN WIRE
MIRROR HEATER
MRH MLH
MRV MLV
MV M+ MR
NCA WIRE
NEAR LEFT "B" PILLAR)
OPERATION SWITCHES
ORG/ WIRE
OUTER MIRROR SWITCH
RED WIRE
RIGHT LEFT
RIGHT OUTER REAR MIRROR
SELECT SWITCHES
UNFOLD FOLD
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> RIGHT OUTER REAR MIRROR
