Lexus IS II (2005-2008) radio receiver assembly swg Wiring diagram
This page shows the only wiring diagram for the component.radio receiver assembly swg, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio receiver assembly swg (1 of 1)
14 5 MOL MOPS
24 25 22 CANL CANH SPD
31 32 NE- NE+
A/C AMPLIFIER MPX+
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY COMPUTER
BRN WIRE
CAIH CAIL
CERTIFI- CATION ECU
CRANKSHAFT POSITION SENSOR
DATA LINK CONNECTOR 3
ECU-IG FUSE
ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT)
ENGINE OIL LEVEL SENSOR
ENGINE OIL PRESSURE SWITCH
ENGINE ROOM 2 J/B (LEFT SIDE OF ENGINE COMPT)
FRONT CONTROLLER
FUEL SENDER GAGE (SUB)
FUEL SUCTION PUMP, GAGE ASSEMBLY
GATEWAY ECU (AT RIGHT END OF DASH)
GRD
GRN WIRE
GRY WIRE
LEFT COWL SIDE J/B (AT LEFT END OF DASH)
LT GRN/BLK WIRE
MPX
MULTI-DISPLAY
NCA WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
POWER WINDOW MASTER SWITCH
RADIO RECEIVER ASSEMBLY SWG
RED WIRE
RED/WHT WIRE
RELAY ENERGIZED
SKID CONTROL ECU
SKID CONTROL ECU W/ ACTUATOR
SPIRAL CABLE
STEERING PAD SWITCH
STEREO COMPONENT AMPLIFIER
TAC
TACH
TACH SPD PNK WIRE
TIRE PRESSURE WARNING ECU
VIO WIRE
VIO/YEL WIRE
WATER LEVEL WARNING SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YEL WIRE
YEL/GRN WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> RADIO RECEIVER ASSEMBLY SWG
