Lexus IS II (2005-2008) main luggage compt door opener switch Wiring diagram
This page shows the only wiring diagram for the component.main luggage compt door opener switch, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram main luggage compt door opener switch (1 of 1)
BLU WIRE
BODY ECU GRD
BODY ECU TR+
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM 1 J/B (RIGHT REAR OF ENGINE COMPT)
FUEL LID OPENER MOTOR (LEFT REAR OF VEHICLE)
FUEL OPEN FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT COWL SIDE J/B (AT LEFT END OF DASH)
LGCY
LH J/B-AM FUSE
LKUL
LPSW
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPT DOOR LOCK CYLINDER
LUGGAGE COMPT DOOR OPENER SWITCH
LUGGAGE DOOR LOCK ASSEMBLY
LUGGAGE ELECTRICAL KEY SWITCH
MAIN LUGGAGE COMPT DOOR OPENER SWITCH
MPX-B FUSE
PNK WIRE
RED WIRE
RIGHT COWL SIDE J/B (AT RIGHT END OF DASH)
SGRD MPXB
TSW TKUL
WHT WIRE
WHT/BLK WIRE
Go to component -> Trunk & fuel door release circuit -> MAIN LUGGAGE COMPT DOOR OPENER SWITCH
