Lexus IS II (2005-2008) h-lp upr fuse fr tail fuse Wiring diagram
This page shows the only wiring diagram for the component.h-lp upr fuse fr tail fuse, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram h-lp upr fuse fr tail fuse (1 of 1)
BLK WIRE
BLU WIRE
COWL SIDE J/B LEFT (AT LEFT END OF DASH)
ECU-IG LH FUSE
ENGINE ROOM J/B 2, ENGINE ROOM R/B 2 (LEFT SIDE OF ENGINE COMPT)
FR FOG FUSE
FR FOG RELAY
FROM MPX-B FUSE (DIAGRAM 1 OF 2)
FRONT CONTROLLER
GRN WIRE
GRN/RED WIRE
H-LP L LWR FUSE
H-LP R LWR FUSE
H-LP UPR FUSE FR TAIL FUSE
HEAD LP RELAY
HI LO
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT FOG LAMP
LEFT HEADLAMP ASSEMBLY
LIGHT CONTROL ECU
LOW (HID)
LOW HIGH
LT GRN WIRE
MAIN FUSE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LAMP
RIGHT HEADLAMP ASSEMBLY
SOLENOID
W/ HID
W/ HID W/O HID
W/O HID
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SYSTEM (HEADLAMP CLEANER CIRCUIT)
YEL WIRE
Go to component -> Headlamps circuit, with drl (2 of 2) -> H-LP UPR FUSE FR TAIL FUSE
