Lexus IS II (2005-2008) front door lcty fuse Wiring diagram
This page shows the only wiring diagram for the component.front door lcty fuse, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front door lcty fuse (1 of 1)
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BODY ECU GRD
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOME FUSE MAIN FUSE
ENGINE ROOM 1 J/B (RIGHT REAR OF ENGINE COMPT)
FOOT LAMP
FRONT DOOR LCTY FUSE
GATEWAY ECU
GRY WIRE
HEAD LP RELAY
HOT AT ALL TIMES
LEFT COWL SIDE J/B (AT LEFT END OF DASH)
LEFT OUTER REAR VIEW MIRROR
LGCY
LKUL
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPT DOOR LOCK CYLINDER
RED/WHT WIRE
RIGHT OUTER REAR VIEW MIRROR
SGRD
TURN SIGNAL FLASHER
VIO WIRE
W/ MEMORY
W/O MEMORY
W/O NAVIGATION SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-theft circuit, without smart key system (3 of 4) -> FRONT DOOR LCTY FUSE
