Lexus IS II (2005-2008) airbbag sensor assembly center Wiring diagrams
This page contains all the electrical diagrams for the component. airbbag sensor assembly center, in which he is found in the car Lexus IS II (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
airbbag sensor assembly center wiring diagram (1 of 2)
AIRBBAG SENSOR ASSEMBLY CENTER
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/ BLU WIRE
BLK/ WHT WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BUCKLE SWITCH
COMBINATION METER SKID CONTROL ECU
COMPUTER DATA LINES SYSTEM
DBE-
ENGINE HOOD COURTESY SWITCH
ENGINE ROOM 1 J/B (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM 2 J/B
FRONT CONTROLLER
GATEWAY ECU
GRN WIRE
GRN/RED WIRE
GRY WIRE
GSW
HORN (HIGH)
HORN (LOW)
HORN FUSE
HORN RELAY
HOT AT ALL TIMES
LEFT FRONT SEAT INNER BELT
MPX
MPX-B FUSE
ORG/ WIRE
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> Anti-theft circuit, with smart key system (4 of 7) -> AIRBBAG SENSOR ASSEMBLY CENTER
airbbag sensor assembly center wiring diagram (2 of 2)
AIRBBAG SENSOR ASSEMBLY CENTER
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLK/ BLU WIRE
BLK/ WHT WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BUCKLE SWITCH
COMBINATION METER SKID CONTROL ECU
COMPUTER DATA LINES SYSTEM
DBE-
ENGINE HOOD COURTESY SWITCH
ENGINE ROOM 1 J/B (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM 2 J/B
FRONT CONTROLLER
GATEWAY ECU
GRN WIRE
GRN/RED WIRE
GRY WIRE
GSW
HORN (HIGH)
HORN (LOW)
HORN FUSE
HORN RELAY
HOT AT ALL TIMES
LEFT FRONT SEAT INNER BELT
MPX
MPX-B FUSE
ORG/ WIRE
RED WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> Power door locks circuit, with smart key system (4 of 7) -> AIRBBAG SENSOR ASSEMBLY CENTER
