Lexus IS II (2005-2008) 23 19 13 14 pkb seuc rev spd Wiring diagram
This page shows the only wiring diagram for the component.23 19 13 14 pkb seuc rev spd, which is found in the car Lexus IS II (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 23 19 13 14 pkb seuc rev spd (1 of 1)
23 19 13 14 PKB SEUC REV SPD
25 24 CANH CANL
32 31 NE+ NR- ENGINE CONTROLS SYSTEM
6 21 17 18 4 13 3 12 GTX+ GTX- NAVIGATION SYSTEM (NAVIGATION CIRCUIT)
A/T
BACK-UP LAMP SWITCH
BLK WIRE
BLU WIRE
BODY COMPUTER BACK
BODY COMPUTER IND
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL
GATEWAY ECU
GRD
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IG BKUP
IG FUSE
INPUT CIRCUIT
INSTRUMENT CLUSTER
LEFT COWL SIDE J/B (AT LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
M/T
MICRO COMPUTER
MPX
MULTI-DISPLAY
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH
PARKING BRAKE SWITCH
PNK PNK WIRE
PNK WIRE
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
RED WIRE
RELAY
RIGHT COWL SIDE J/B (AT RIGHT END OF DASH)
SKID CONTROL ECU
SPEEDOMETER +S
STEREO COMPONENT AMPLIFIER
VIO WIRE
W/ VEHICLE DYNAMICS INTEGRATED MANAGEMENT
W/O VEHICLE DYNAMICS INTEGRATED MANAGEMENT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Rear view monitoring circuit -> 23 19 13 14 PKB SEUC REV SPD
