Ground distribution circuit for Lexus IS I (1999-2005)

BACK DOOR OPENER RELAY BACK DOOR COURTESY SWITCH AND OPENER MOTOR BJ (BASE OF LEFT "B" PILLAR) BLK WIRE BODY ECU CENTER AIRBAG SENSOR ASSEMBLY CIGARETTE LIGHTER DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) FLASH RELAY FRONT AND REAR WIPER AND WASHER SWITCH (COMBINATION SWITCH) FUEL PUMP HIGH MOUNTED STOP LIGHT JUNCTION CONNECTOR J/C 11 (IN LEFT FRONT DOOR) LEFT BUCKLE SWITCH LEFT FRONT DOOR KEY LOCK, UNLOCK SWITCH, DOOR LOCK DETECTION SWITCH LEFT LICENSE PLATE LIGHT LEFT REAR DOOR LOCK MOTOR AND DOOR LOCK DETECTION SWITCH LEFT REAR POWER WINDOW CONTROL SWITCH LEFT REMOTE CONTROL MIRROR LEFT TAILLIGHT (LEFT REAR COMBINATION LIGHT) LIGHT CONTROL SWITCH AND DIMMER SWITCH (COMBINATION SWITCH) LIGHT FAILURE SENSOR LUGGAGE COMPARTMENT DOOR KEY UNLOCK SWITCH LUGGAGE COMPARTMENT DOOR OPENER RELAY NOISE FILTER (DEF CDS) NOISE FILTER (DEF CDS) NOISE FILTER (STOP LIGHT) NOISE FILTER (STOP LIGHT) REAR SIDE MARKER LIGHT POWER SEAT CONTROL SWITCH (DRIVER'S SEAT) POWER WINDOW MASTER SWITCH REAR FOG LIGHT SWITCH REMOTE CONTROL MIRROR SWITCH RIGHT STOP LIGHT (RIGHT REAR COMBINATION LIGHT) RIGHT TAILLIGHT (RIGHT REAR COMBINATION LIGHT) SEAT HEATER (DRIVER'S SEAT) SEAT HEATER (DRIVER'S SEAT) LEFT BUCKLE SWITCH SEDAN SEDAN ONLY SEDAN WAGON STEERING SENSOR THEFT DETERRENT ECU TO GROUND BM (DIAGRAM 2 OF 3) TO J/C 5 (DIAGRAM 2 OF 3) TRANSPONDER KEY AMPLIFIER TURN SIGNAL SWITCH (COMBINATION SWITCH) UNLOCK WARNING SWITCH W/ POWER SEAT WAGON WAGON ONLY WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK CONTROL RECEIVER

A/C DUAL PRESSURE SWITCH A/C SINGLE PRESSURE SWITCH LEFT HEADLIGHT CONTROL ECU RADIATOR FAN MOTOR A/T BACK DOOR OPENER SWITCH BLK WIRE BLOWER MOTOR CONTROLLER BM (LOWER LEFT SIDE OF LUGGAGE COMPARTMENT) BN (LOWER RIGHT SIDE OF LUGGAGE COMPARTMENT) BRAKE FLUID LEVEL WARNING SWITCH BRN WIRE BRN/YEL WIRE COMBINATION SWITCH DRIVER SIDE J/B (DIAGRAM 1 OF 3) EA (FRONT SIDE OF INTAKE MANIFOLD) EC (REAR OF LEFT FRONT FENDER) ENGINE CONTROL MODULE ENGINE HOOD COURTESY SWITCH ENGINE OIL LEVEL SENSOR ENGINE ROOM NO. 3 R/B FAN NO. 2 RELAY FROM JUNCTION CONNECTOR J/C 15 (DIAGRAM 1 OF 3) FRONT WINDOW DEICER FRONT WIPER MOTOR HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) COMBINATION SWITCH HEATED OXYGEN SENSOR BANK 1 SENSOR 1 HEATED OXYGEN SENSOR BANK 2 SENSOR 2 HIGH MOUNTED STOP LIGHT IF (LOWER RIGHT CENTER OF DASH, FORWARD OF CENTER FLOOR CONSOLE) IG (BEHIND UPPER RIGHT END OF DASH) IGNITER INNER MIRROR JUNCTION CONNECTOR J/C 5 (BEHIND LEFT SIDE OF DASH, BEHIND DRIVER SIDE J/B) JUNCTION CONNECTOR J/C 7 (BEHIND UPPER RIGHT SIDE OF DASH) LEFT FRONT FOG LIGHT HEADLIGHT CLEANER CONTROL RELAY LEFT FRONT PARKING LIGHT LEFT FRONT SIDE MARKER LIGHT LEFT FRONT SIDE TURN SIGNAL LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT LICENSE PLATE LIGHT LEFT REAR COMBINATION LIGHT LEFT VANITY LIGHT M/T MOON ROOF CONTROL ECU MOON ROOF CONTROL SWITCH PERSONAL LIGHT REAR WINDOW DEFOGGER REAR WIPER MOTOR REMOTE CONTROLLER (NAVIGATION) MULTI- DISPLAY RIGHT LICENSE PLATE LIGHT RIGHT REAR COMBINATION LIGHT RIGHT VANITY LIGHT SKID CONTROL ECU STEREO COMPONENT AMPLIFIER RADIO AND PLAYER TO GROUND BJ (DIAGRAM 1 OF 3) W/ MOON- ROOF W/O MOON- ROOF WAGON ONLY WHT WIRE WHT/BLK WIRE WIRE TO FCC HOLDER (IN ROOF, NEAR MOON ROOF ECU) YEL WIRE

A/C CONTROL ASSEMBLY A/T ABS, BA, TRAC ACTUATOR ABS, BA, TRAC, VSC ACTUATOR BK (UNDER RIGHT FRONT SEAT) BLK WIRE BRN WIRE CENTER AIR BAG SENSOR ASSEMBLY COMBINATION METER DATA LINK CONNECTOR (DLC) 3 DAYTIME RUNNING LIGHT RELAY (MAIN) DAYTIME RUNNING LIGHT RELAY NO. 3 DAYTIME RUNNING LIGHT RELAY NO. 4 DAYTIME RUNNING LIGHT RESISTOR EFI RELAY ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH ENGINE ROOM NO. 1 R/B (RIGHT REAR OF ENGINE COMPT) ENGINE ROOM NO. 2 R/B (RIGHT REAR OF ENGINE COMPT) GLOVE BOX LIGHT HEADLIGHT BEAM LEVEL CONTROL ECU IH (BEHIND RIGHT KICK PANEL) JUNCTION CONNECTOR J/C 16 (ABOVE RIGHT REAR FENDER- WELL) JUNCTION CONNECTOR J/C 7 (BEHIND UPPER RIGHT SIDE OF DASH) M/T NAVIGATION ECU PASSENGER SIDE J/B (BEHIND LOWER RIGHT END OF DASH) POWER OUTAGE (LUGGAGE) POWER OUTLET POWER OUTLET RELAY POWER SEAT CONTROL SWITCH (FRONT PASSENGER'S SEAT) RHEOSTAT RIGHT BUCKLE SWITCH AND SEAT BELT WARNING OCCUPANT DETECTION SENSOR RIGHT DOOR LOCK CONTROL SWITCH RIGHT FRONT DOOR LOCK MOTOR AND DOOR LOCK DETECTION SWITCH RIGHT FRONT FOG LIGHT RIGHT FRONT PARKING LIGHT RIGHT FRONT POWER WINDOW CONTROL SWITCH RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT SIDE TURN SIGNAL LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT HEADLIGHT CONTROL ECU RIGHT MIRROR HEATER (REMOTE CONTROL MIRROR) RIGHT REAR DOOR LOCK MOTOR AND DOOR LOCK DETECTION SWITCH RIGHT REAR POWER WINDOW CONTROL SWITCH SEAT HEATER (FRONT PASSENGER'S SEAT) SEAT HEATER SWITCH (DRIVER'S SEAT) SEAT HEATER SWITCH (FRONT PASSENGER'S SEAT) SEDAN SHIFT LOCK CONTROL ECU STARTER RELAY TRAC OFF SWITCH TRAC OFF SWITCH AND SNOW SWITCH W/ POWER SEATS W/ VSC W/O POWER SEATS W/O VSC WAGON WATER TEMPERATURE SWITCH WHT WIRE WHT/BLK WIRE WIRELESS DOOR LOCK CONTROL RECEIVER WOOFER
