Lexus IS I (1999-2005) tail rru rrd Wiring diagram
This page shows the only wiring diagram for the component.tail rru rrd, which is found in the car Lexus IS I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail rru rrd (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 PRG RDA DBKL LSR RCTY DCTY LGCY TR+ RLU RLD
1 2 3 4 5 6 7 BSUB BECU IG
8 9 ILE ACT+
ANTI-THEFT SYSTEM
BLK/RED WIRE
BLK/YEL WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU (BEHIND LOWER LEFT END OF DASH, INTEGRAL WITH DRIVER SIDE J/B)
BRN/WHT WIRE
BZR PU PD
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DFG
DOOR FUSE
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
ECU-IG FUSE
FE FR
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
HOT W/ TAIL RELAY ENERGIZED
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM
INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM EXTERIOR LIGHTS SYSTEM
JUNCTION CONNECTOR 5 (BEHIND LEFT END OF DASH, ABOVE DRIVER SIDE J/B)
KSW PML PCTY PMUL HAZ DCLP PCLP BDSU LSWP
MPX-B FUSE
ORG/ WIRE
PANEL FUSE
PASSENGER SIDE J/B (BEHIND LOWER RIGHT END OF DASH)
PNK/BLK WIRE
POWER WINDOWS SYSTEM
POWER WINDOWS SYSTEM ENGINE CONTROLS SYSTEM
POWER WINDOWS SYSTEM POWER TOPS SYSTEM
RADIO 2 FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
TAIL RRU RRD
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WAGON
WARNING SYSTEM DOOR LOCKS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Body control modules circuit -> TAIL RRU RRD
