Lexus IS I (1999-2005) key inter lock solenoid Wiring diagram
This page shows the only wiring diagram for the component.key inter lock solenoid, which is found in the car Lexus IS I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram key inter lock solenoid (1 of 1)
1 2 3 4 5 6 7 8 9 10 NSSD
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) GAUGE FUSE
ECU-IG FUSE
ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT, IN PROTECTIVE CASE)
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IH (AT RIGHT SIDE OF FIREWALL)
J/C 1, J/C 2 (ON LEFT SIDE OF ENGINE COMPT, NEAR ENGINE CONTROL MODULE)
J/C 10 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 5 (BEHIND LEFT END OF DASH)
J/C 7 (BEHIND UPPER RIGHT SIDE OF DASH)
KEY INTER LOCK SOLENOID
KLS+
LT GRN/BLK WIRE
PASSENGER SIDE J/B (BEHIND LOWER RIGHT END OF DASH)
RADIO 2 FUSE
RED WIRE
SHIFT LOCK CONTROL ECU (BELOW RIGHT SIDE OF TRANSMISSION SHIFT LEVER)
SHIFT LOCK CONTROL SWITCH
SHIFT LOCK SOLENOID
SLS+ SLS-
STOP FUSE
STOPLIGHT SWITCH
UNLOCK WARNING SWITCH
WHT WIRE
Go to component -> Shift interlock circuit -> KEY INTER LOCK SOLENOID
