Lexus IS I (1999-2005) engine control module (on left front of engine compt, in Wiring diagram
This page shows the only wiring diagram for the component.engine control module (on left front of engine compt, in, which is found in the car Lexus IS I (1999-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine control module (on left front of engine compt, in (1 of 1)
A/C CONTROL ASSEMBLY
BACK DOOR COURTESY SWITCH, OPENER MOTOR (AT CENTER REAR OF LUGGAGE COMPT)
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMBINATION METER
DATA LINK CONNECTOR 3 (BEHIND LOWER LEFT SIDE OF DASH) CG SIL
DOME FUSE
EB (AT CENTER LEFT SIDE OF INTAKE MANIFOLD)
ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT, IN
GRN/YEL WIRE
HOT AT ALL TIMES
IH (AT RIGHT SIDE OF FIREWALL)
JUNCTION CONNECTOR 12 (ABOVE LEFT REAR FENDERWELL)
JUNCTION CONNECTOR 17 (ABOVE LEFT REAR FENDERWELL)
LUGGAGE COMPT DOOR COURTESY SWITCH, OPENER MOTOR
MPX
MPX-B FUSE
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND LOWER RIGHT END OF DASH)
PROTECTIVE CASE)
RED/YEL WIRE
SEDAN
THEFT DETERRENT ECU (BEHIND LEFT END OF DASH)
WAGON
WHT WIRE
WHT/BLK WIRE
Go to component -> Power door locks circuit (3 of 3) -> ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT, IN
